Description
HDMI Extender Over Cat6/6A/7 4k@30Hz up to 40m 1080P up to 70M zero latency IR & POC support Transmitter and Receiver kit
This HDMI Extender includes a transmitter unit and a receiver unit allows the HDMI signal to be transmitted up to 70 meters at 1080p resolution using a Cat6/6A/7 network cable.
It adopts a pointtopoint connection configuration supports IR passback. It is perfect for outdoor advertising monitor system home entertainment conference etc
HDMI & IR Extender Kit Over Cat6/6A/7. 1080p up to 70m. Supports EDID & IR Passback. Support PoC network cable power supply only TX power supply is needed (Not Suitable for Cat5/5e)
Zero latency
Support up to 4K@30Hz resolution
Support CAT6/6A/7 network cables 1080p@60Hz transmission distance is up to 70meters 4K@30Hz transmission distance is up to 40 meters
Support IR passback function (20KHz~60KHz)
Support HDR10
Support EDID passthrough
Support PoC network cable power supply
Only TX power supply is needed
Power Supply
Voltage/Current:DC 5V/2A
Power consumption:TX+RX
HDMI Performance and Interface
HDMI resolution:800×600 1024×768 1280×720 1280×960 1366×768 1440×900 1680×1050
1920×1080 480i@60Hz 480p@60Hz 576i@50Hz 576p@50Hz 720p@50/60Hz 1080i@50/60Hz
1080p@24/25/30/50/60Hz 3840×2160@24/25/30Hz
Audio formats:DTS DTSHD PCM LPCM
HDR:Support
EDID through:Support
IR Passback:Frequency Range: 20KHz~60KHz
Input and output TMDS signal:0.7~1.2Vpp (TMDS)
Input and output DDC signal:5Vpp (TTL)
Transmission Distance:Cat6/6A/7
1080p@60Hz transmission 70 metres
4K@30Hz transmission 40 metres 1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV)
Protection Level:Electrostatic protection of the whole machine Implementation of the standard: IEC6100042
Operating Environment:
Working temperature:20°C~60°C
Storage temperature:30°C~70°C
Humidity (no condensation) 0%~90% RH
Body Properties
Dimension:75.0(L) x 60.0(W) x 16.5(H) mm
Weight: 127g
Warranty: 180 days
Package included:
1x transmitter unit (TX)
1x receiver unit (RX)
1x IR blaster extension cable
1x IR receiver extension cable
1x DC5V/2A adapter
1x user manual
